Products
Air-Jet Reeds
| Name | Code | Scale |
|---|---|---|
| Reed count | N | 16-144/2" |
| Width of dent | b | 4 mm |
| Total width | B | ≤6000 mm |
| Useful width | BN | buyers option |
| Total height | h1 | 100 - 122 mm |
| Inner height of reed | e | 60 - 80 mm |
| Height of air current guide | h2 | 56, 54, 57 mm |
Projectile / Rapier Reeds
| Name | Code | Scale |
|---|---|---|
| Reed count | 16 x 146 /2"" | |
| Total width | L | ≤6000 mm |
| Useful width | L1 | byers option |
| Total height | H | 90 - 180 mm |
| Width of dents | b | 4.0 mm |
| Height of top baulk | h1 | 10/12 mm |
| Height of bottom baulk | h2 | 18/20 mm |
| Thickness of baulk | d | 8.0 mm |
